This assembly consists of a six-inch diameter concrete-filled painted steel pipe bollard topped with a prefabricated cap secured by a headed stud anchor. The bollard is embedded within an eighteen-inch diameter concrete footing. The surrounding reinforced concrete slab or pavement is separated from the footing by an expansion board with a removable cap and continuous sealant. At the exterior face, the slab is sloped and finished with continuous sealant. All exterior bollards must be galvanized and primed to receive a final paint finish.
Text on the drawing
CONT. SEALANT (EXTERIOR ONLY) REINF. CONC. SLAB/PAVEMENT (GRADE LINE @ LANDSCAPE AREAS) SLOPE CONC. NOTE: ALL EXTERIOR BOLLARDS SHALL BE GALVANIZED AND PRIMED AS REQUIRED FOR FINISH PAINTING 18" DIA. CONCRETE FOOTING PREFABRICATED BOLLARD CAP W/ HEADED STUD ANCHOR 6" DIA. CONCRETE FILLED PAINTED STL. PIPE BOLLARD 2' - 6" 6" 4' - 0" EXPANSION BD. W/ REMOVABLE CAP & CONT. SEALANT
