The drawing details fixed width frame profiles including a lead-lined intermediate mullion for between-glass venetian blinds and a matching louver profile. The mullion assembly incorporates removable stops on both sides and a blind tilt control as required, with dimensions indicating equal spacing and a throat opening plus one inch. The louver profile is detailed with specific flange dimensions and throat opening clearances.
2" 5/8" 2" 4" 5/8" 2" 1/2" 1/2" THROAT OPENING MULLION - BETWEEN GLASS VENETIAN BLIND (LEAD LINED) W9X LOUVER W10 REMOVABLE STOP (BOTH SIDES) BLIND TILT CONTROL AS REQD AS REQD EQ EQ LEAD LINING LOUVER THROAT OPENING + 1"
