This plan detail shows a hollow structural section measuring 4x4 by 5/16 inches welded to a steel base plate of three-eighths-inch thickness as required. The connection is secured with two five-eighths-inch diameter by six-inch embedment ASTM F1554 anchor bolts featuring heavy hex nuts or bolt heads at the bottom. A three-sixteenths-inch fillet weld joins the steel post to the base plate.
7 1/2" 7 1/2" 2 1/2" 2 1/2" 1" 1 1/2" 1/2" 1/2" F PLAN 3/16" HSS 4 X 4 X 5 16 STEEL POST BASE PL. 3 8 " X AS REQ'D W/ (2) - 5 8 " DIA. X 6" EMBED. F1554 ANCHOR BOLTS W/ HEAVY HEX NUT OR BOLT HEAD AT BOT.
