A scupper flashing assembly features sheet metal joint details. A twelve-inch clear opening includes six-inch side flanges and variable clearance dimensions referenced to wall sections. Detail callouts A-A and B-B incorporate the interlocking flat lock seam and hemmed edge profiles used in the sheet metal construction. Multiple dimensional arrows establish clearances ranging from two inches to twenty-four inches across the assembly.
CLR. DIM. VARIES - REF. WALL SECTIONS A 6" CLEAR 12" CLEAR 24" 6" 6" 6" A +/- 1'-8" CLR. 2" VARIES 4" A-A B-B 1 B 1 6" B 2" 2"
