A-77JMY — Brick Offset at Staircore

Architectural · A-77JMY

Brick Offset at Staircore

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: A7.21
Discipline: Architectural

Materials

Brick Gypsum / Drywall Steel

Elements

Anchors / Embeds Beams Expansion / Control Joints Facades / Cladding Floors / Slabs Stairs Waterproofing / Flashing

Connections

Bolted Connection Welded Connection

Text on the drawing

2ND FL. 440' - 7 3/4" C EW2 EW2 2" 2" 437' - 11 3/4" DRIFT DEFLECTION JOINT B.O. SHELF ANGEL EW2 EW2 DRIFT DEFLECTION JOINT PER STRUCTURAL GWB CONTROL JOINT SEALANT SEALANT BEAM PER STRUCTURAL A7.21 2 Sim
