A structural slab receives a sloped mortar setting bed with a metal-reinforced waterproof decoupling membrane tied directly into the shower drain body. Gravel is placed at the clamping ring weeps with sealant to maintain drainage pathways. The tile finish matches the schedule across the sloped floor. A framed partition with tile board and a shower curtain aligns adjacent to the assembly.
STRUCTURAL SLAB TILE AS SCHED SHOWER CURTAIN AS SCHEDULED DRAIN, SEE PLUMBING DRAWINGS PARTITION AS SCHEDULED WITH TILE BOARD MORTAR SETTING BED, SLOPED TO DRAIN, MTL REINFORCED WP DECOUPLING MEMBRANE TIED INTO DRAIN. TILE AS SCHED GRAVEL AT CLAMPING RING WEEPS SLOPE TO DRAIN BODY AND WEEPS SEALANT EQ EQ 4 1/2"
