A 3/8-inch by 16 right-hand threaded rod connects to an internally threaded anchor embedded in the overhead structure. A turnbuckle connector joins the upper rod to a lower threaded section attached to the ceiling main runner. A perimeter wall angle with fasteners secures the partition edge against the wall while allowing vertical movement.
FLOATING INSTALLATION 3/8" - 16 RH THREADED CONNECTION TO CONNECTOR TURNBUCKLE CONNECTOR INTERNALLY THREADED ANCHOR 3/8" 16 THREADED ROD CONNECTION TO DECKING / STRUCTURE PERIMETER CONNECTORS FIELD WALL ANGLE W/ FASTENER MAIN RUNNER STRUCTURE ABOVE WALL (REFER TO PLANS FOR PARTITION TYPE)
