Text on the drawing
CANVAS AWNING 1 1/2" WELDED ALUMINUM FRAME 4X8X1/2 PLATE TAB AND Z-CLIP (NOT SHOWN) L 4X3 STEEL ANGLE DECK SUPPORTS WELDED TO FRAME C 6X2 CANOPY FRAME WELDED AND MITERED AT CORNERS 2 AWNING AXONOMETRIC NOT TO SCALE
