A custom ornamental ceiling rosette is laid out on orthogonal centerlines with a radius of four and one-half inches, an overall diameter of nine and three-eighths inches, and a projection of one and three-quarters inches. The decorative element is based on Faber Ornamental Plastering Corp part number CM-037. Reference is made to sheet A1 on drawing A-662 for the corresponding mounting section detail.
CL CL R 4 1/2" DESIGN BASED ON FABER ORNAMENTAL PLASTERING CORP PART NUMBER CM-037 D = 9-3/8" P = 1-3/4" FOR MOUNTING SECTION DETAIL SEE A1/A-662
