A hollow metal frame connects to a steel stud partition framed with gypsum wallboard on both sides. Jamb anchors secure the frame to the wall assembly, with spot grout placed at the anchor locations. Dashed lines indicate the position of a perpendicular wall condition where applicable.
VARIES 1 9/16" 5/8" 5/8" 2" 5/8" 1 15/16" 4" SEE PARTITION TYPE FOR VARYING CONDITIONS DASHED LINES REPRESENT PERPENDICULAR WALL WHEN APPLICABLE SPOT GROUT AT JAMB ANCHORS 08 1113 HM FRAME 09 2216 STEEL STUD 08 1113 JAMB ANCHOR
