A balanced glass entrance door rests above a concrete slab on grade with an integrated fiber expansion joint and liquid-applied flashing secured by a metal termination bar. Extruded polystyrene foam-plastic insulation and molded-sheet drainage panels line the slab edge. A two-inch gap accommodates thermal and structural movement beneath the threshold assembly.
08 41 13.B MANUAL-SWING ENTRANCE DOOR 07 95 13.B3 FIBER EXPANSION JOINT SLAB ON GRADE 2" 07 14 13.C MOLDED-SHEET DRAINAGE PANELS 07 21 00.B EXTRUDED POLYSTYRENE FOAM-PLASTIC 07 52 00 METAL TERMINATION BAR 07 62 00.K7 LIQUID APPLIED FLASHING
