A-6ZXH4 — Plan Detail Room 122

Architectural · A-6ZXH4

Plan Detail Room 122

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Elements

Columns Expansion / Control Joints Floors / Slabs Partitions Walls

Connections

Expansion / Slip Connection

Text on the drawing

7 ACOUSTIC/FIRE-RATED WALL ASSEMBLY, RE: FLOOR PLANS WALL ASSEMBLY RE: FLOOR PLANS ACOUSTIC/FIRE-RATED WALL ASSEMBLY, RE: FLOOR PLANS ISOLATION STRIP BETWEEN STUD & COLUMN
