Mineral wool insulation fills the metal deck flutes at the steel beam support bearing beneath the floor assembly. The exterior wall base incorporates waterproofing and insulation layers transitioning between the interior floor and the exterior balcony slab.
R Q.2 E3 F2 / 10 AA5.34 TYPICAL BASE DETAIL, P1 F7 MINERAL WOOL INSULATION AT METAL DECK FLUTES
