An aluminum sheet metal counter flashing with an interlocking joint protects the top of the masonry wall beneath the new roof metal deck. A continuous gutter finished to match adjacent roofing is mounted alongside the wall with a five-inch projection. The assembly ties into a reinforced concrete masonry unit wall designated as WA6.
5" PLAN DIM CONT GUTTER FINISHED TO MATCH ADJACENT ROOFING N ROOF METAL DECK ALUM SHEET METAL COUNTER FLASHING WITH INTERLOCKING JOINT WA6 YARD TRASH
