Fourteen three-inch diameter Dywidag anchors with a yield strength of 120 ksi are cast into the column base per the referenced base plate details. Sixteen number 10 vertical reinforcing bars of ASTM A706 grade 80 steel are tied within the concrete section. Additional confinement and dowel configurations tie into the adjacent structural wall elements.
(16) #10 VERT BARS A706 GR 80 (14) 3.0" DIA. DYWIDAG ANCHORS Fy = 120 KSI SEE BASE PLATE DETAILS FOR ANCHOR LOCATIONS TYP
