A recessed fluorescent light fixture is integrated into a suspended ceiling grid consisting of main structural runners spaced four feet on center and perpendicular cross tees. Twelve-gauge fixture support wires secure the center ends of each fixture to the overhead structure. Twelve-gauge lateral support wires attach within three inches of each fixture corner, splayed outward and fastened to a beam or purlin. Each connection point requires a minimum of three wire turns.
RECESSED FLUORESCENT FIXTURE CROSS TIE MAIN STRUCTURAL RUNNER 4' - 0" O.C. 12 GA. LATERAL SUPPORT WIRE WITHIN 3" OF EACH CORNER OF LIGHT FIXTURE. SPLAY WIRES AS SHOWN AND FASTEN TO BEAM OR PURLIN. MIN. OF 3 WIRE TURNS EACH CONNECTION POINT 12 GA. FIXTURE SUPPORT WIRES AT CENTER ENDS OF EACH FIXTURE. FIXTURE SUPPORT WIRE SUPPLIED BY CEILING CONTRACTOR
