A roof edge flashing assembly ties a TPO single-ply roofing membrane into a concrete tilt-up wall. The single-ply membrane is sealed and fastened at twenty-four inches on center on both sides over sloped rigid insulation. A continuous cleat is fastened at sixteen inches on center along the parapet edge to secure the metal flashing. Below the roof assembly, a steel deck is supported behind the concrete tilt-up panel.
SEAL TPO SINGLE PLY ROOFING FASTENED @ 24" O.C. BOTH SIDES RIGID INSULATION A A SLOPED INWARD CONTINUOUS CLEAT FASTENED @ 16" O.C. SECTION AA STEEL DECK (SEE STRUCT.) CONCRETE TILT- UP PANEL
