A hollow metal door and frame bears directly on a structural threshold located above a concrete slab on grade. The exterior side transitions to an adjacent concrete pad or sidewalk provided by others, while the interior rests on the main interior slab. A concrete panel and compacted sub-base support the slab assembly.
INTERIOR EXTERIOR HOLLOW METAL DOOR AND FRAME THRESHOLD, SEE SCHEDULE. SLAB ON GRADE CONCRETE PANEL CONCRETE PAD OR SIDEWALK, BY OTHERS DOOR BOTTOM, SEE SCHEDULE
