A prefabricated safety guard rail system matches the Rite-Hite GuardRite protective railing in prefinished safety yellow. The assembly consists of five-inch by five-inch vertical steel posts spaced per plan and secured to a concrete slab. Highway rails bolt directly to the posts using four three-quarter-inch diameter serrated bolts with a minimum four-inch embedment. The total height of the guard rail is three feet eight inches, with intermediate rails positioned at one foot five inches and three feet five inches.
(4) 3/4" DIA SERRATED BOLTS - MIN 4" EMBEDMENT PREFABRICATED GUARD RAIL EQUAL TO RITE-HITE "GUARDRITE" PROTECTIVE RAILING - PREFINISHED SAFETY YELLOW HIGHWAY RAILS BOLTED TO POST 5" X 5" POST 3' - 8" SEE PLAN EQUAL SPACING FOR POST 3' - 5" 1' - 5"
