A single ply roofing system sits over a cover board atop a metal deck and structural steel framing at the roof platform elevation of 149 feet 10 inches. A one and one-quarter inch steel pipe post extends upward through a base support above the roof assembly. A roofing membrane over a cover board wraps the exterior plenum wall extending down to the lower roof level at 144 feet.
ROOF 144' - 0" T.O. PLATFORM 149' - 10" 1 1/4" STEEL PIPE POST / A7.82 7 ROOFING MEMBRANE OVER COVER BOARD SINGLE PLY ROOFING SYSTEM
