The layout establishes accessibility clearance zones for a manual swinging door on the push side with a latch approach. The floor area requires a minimum twenty-four-inch clearance beyond the latch edge and a minimum forty-eight-inch depth perpendicular to the doorway. A door closer is provided to comply with operational force and closing speed requirements.
MANEUVERING CLEARANCES AT MANUAL LATCH APPROACH – PUSH SIDE, DOOR PROVIDED WITH CLOSER (k) 24” Min. 48” Min. MANEUVERING CLEARANCES AT MANUAL SWINGING DOORS & GATES
