A one and a half inch outer diameter stainless steel handrail connects to a post using a half inch stainless steel rod and a three sixteenths inch stainless steel cap plate. The handrail post extends into a two inch diameter pipe sleeve featuring an eighth inch bottom closure plate embedded within a concrete filled steel pan stair. Three eighth inch steel stiffener plates are spaced typically at each post and welded to the sleeve and tread. A steel channel stringer supports the stair assembly while adjacent gypsum wallboard and metal framed walls or guardrails are provided per plan.
1-1/2" OD SSTL HANDRAIL 3" 1/2" SSTL ROD 3/16" SSTL CAP PLATE 1 1/2" OD SSTL HANDRAIL POST 1/8 TYP GUARDRAIL OR PARTITION PER PLAN STL CHANNEL STRINGER 1-1/2" OD SSTL HANDRAIL POST 2" DIA PIPE SLEEVE W/ 1/8" BOTTOM CLOSURE PLATE CONC FILLED STL PAN STAIR 1/8" STL STIFFENER PLATE, TYP OF (3) @ EACH POST 1/8 TYP SLEEVE TO TREAD 1/8 TYP STIFF. PL TO SLEEVE/TREAD 1-1/2" OD SSTL HANDRAIL POST 2" DIA PIPE SLEEVE W/ 1/8" BOTTOM CLOSURE PLATE 1/8" STIFFENER PLATE, TYP OF (3) @ EACH POST 1 1/2" CLR FOR POST DIMS VARIES: REF SECTIONS STL CHANNEL STRINGER; GWB AND MTL FRAMED WALL/GDRL ABOVE HIDDEN FOR CLARITY CONC FILLED STL PAN STAIR D. SECTION @ BASE C. SECTION @ HDRL TO POST CONN
