An access panel is integrated into a gypsum board ceiling system using 1 1/2-inch by 1 1/2-inch by 25-gauge sheet metal angles placed at each side of the opening. The angles are secured with a minimum of two number 8 self-tapping sheet metal screws. The assembly connects to the metal frame beyond and the ceiling attachment for the specified ceiling system.
1 1/2" X 11/2" X 25 GA SM ANGLE @ EACH SIDE OF ACCESS PANEL OPENING, ATTACH W/ MIN (2) #8 SELF TAP SM SCREWS LINE OF MTL FRAME BEYOND CEILING ATTACHMENT ACP CEILING SYSTEM, PER SCHED. MTL ACCESS PANEL
