This parapet wall termination features a double 2x wood top plate supporting a metal coping secured with proprietary anchor clips and fasteners. The coping provides a minimum three-and-a-half-inch profile with a weep metal edge on the exterior side. An ethylene propylene diene monomer membrane is adhered to the wall assembly, transitioning with a cant strip at the low roof junction. The exterior face is finished with three-quarters of an inch of lath and plaster with paint.
3/4" LATH & PLASTER, [ST-1] PAINT, TYP. WALL TYPE C WEEP METAL EDGE 3/8" MIN METAL COPING DOUBLE 2X WOOD TOP PLATE ANCHOR CLIP 1 1/4" HOT DIPPED GALV. ROOF NAILS @ 4" O.C. MAX EPDM MEMBRANE BONDING ADHESIVE 3 1/2" 8 7/8" ANCHOR CLIP FASTENERS (SUPPLIED W/ COPING) CANT STRIP MIN 6"
