The curtain wall door head assembly integrates an aluminum storefront door frame below a structural silicone glazed aluminum mullion and vision glass. The head frame includes a continuous aluminum curtain wall head profile anchored beneath vision glass with designated dimension points and vertical clearances. The door unit is specified per the door schedule with a five-inch frame width. Dimension indicators establish the finished opening height, varying between seven inches at low spans and nine and a quarter inches at high spans.
DIM. PT. F.O.G. CW DOOR HEAD 1/2" 1" 1/2" CW DOOR PER SCHEDULE VISION GLASS AL. SSG MULLION 7" AT LOW SPAN 9 1/4" AT HIGH SPAN 5"
