A continuous steel pipe top rail is positioned at three feet six inches above finished floor to serve as the top of the guardrail. A separate steel pipe handrail is mounted at three feet zero and one-half inches above finished floor, supported by a three-quarter-inch plate handrail support with a one and one-eighth-inch radius curve. A minimum clearance of one and one-half inches is maintained below the bottom of the handrail gripping surface in accordance with accessibility requirements. Intermediate rails are omitted from the view for clarity.
3'-6" A.F.F. 3'-1/2" A.F.F. T.O. GUARDRAIL T.O. HANDRAIL 1 1/2" 1 1/2" 1 1/2" 1 1/2" CONTINUOUS STEEL PIPE RAIL STEEL PIPE HANDRAIL 3/4" PLATE HANDRAIL SUPPORT NOTE: INTERMEDIATE RAILS NOT SHOWN FOR CLARITY 2 3/4" R 1 1/8" HORIZONTAL PROJECTION TO ACCUR 1 1/2" MIN. BELOW BOTTOM OF HANDRAIL GRIPPING SURFACE (CBC 11B-505.6) 1 1/2"
