An open wall cabinet bottom assembly features a 1-1/2-inch fascia with heavy duty edgebanding matching the specified cabinet finish. Finished edges return at exposed end cabinets with a seamless fascia finish. An LED light as specified in electrical drawings is integrated into the underside.
LED LIGHT AS SPECIFIED (SEE ELEC) RETURN FINISHED EDGE AT EXPOSED (END) CABINETS *FASCIA FINISH TO BE SEAMLESS 0' - 1 1/2" HEAVY DUTY EDGEBANDING TO MATCH CABINET FINISH SPECIFIED.
