A high speed overhead coiling metal door is set within an eighteen foot opening height bounded by a W30 hangar door frame. Fourteen by six steel tube jamb subframes line each side of the opening, supporting a twelve by six steel tube header at the top. The coiling door assembly utilizes a Rytec Spiral SST-HZ basis of design with a door bottom seal and designated DJ8/A363, DH8/A363, and DS3/A363 markings. The framing maintains a five foot minimum clear dimension alongside the specified opening height per schedule.
18'-0" OPENING HEIGHT W30 HANGAR DOOR FRAME 14x6 STEEL TUBE JAMB SUB FRAME EACH SIDE 12x6 STEEL TUBE HEADER HIGH SPEED OVH COILING DOOR. BASIS OF DESIGN: SPIRAL SST-HZ BY RYTEC 5'-0" MIN CLEAR W30 HANGAR DOOR FRAME DOOR BOTTOM SEAL DJ8/A363 DH8/A363 DS3/A363 HSM HIGH SPEED OVERHEAD COILING METAL DOOR LOCATED IN HANGAR DOOR BASIS OF DESIGN: SPIRAL SST-HZ BY RYTEC OPENING HEIGHT PER SCHD
