Weather seal configuration at the meeting stile between two hangar doors. The assembly features W30 door stiles equipped with compressible neoprene seals at the exterior and interior junctions to prevent air and moisture infiltration. The exterior side is clad with prefinished insulated core metal panels, utilizing Max-Rib profiles by McElroy, secured with trim fasteners and sealant tape over prefinished metal trim. The interior side incorporates metal liner panels extending to eight feet high. Coordination with the primary hangar door drawings is required for stile and seal specifications.
EXTERIOR SIDE: PREFINISHED INSULATED CORE METAL PANEL INTERIOR SIDE: METAL LINER PANEL TO 8'-0". BASIS OF DESIGN: MAX-RIB BY MCELROY PREFINISHED METAL TRIM W30 DOOR STILE (REF HANGAR DOOR DRAWINGS) TRIM FASTENERS AND SEALANT TAPE COMPRESSIBLE NEOPRENE SEAL (REF HANGAR DOOR DRAWINGS)
