An overhead cabinet features one adjustable plastic laminate shelf and an opening in the back for an owner-supplied and installed microwave with specified clearances. The cabinet box consists of one-half-inch material with plastic laminate finish on all exposed surfaces. A waste receptacle assembly incorporates a three-eighths-inch thick bronze ledge with a polished front edge and a receptacle slot. A three-sixteenths-inch bronze door is hung on an oil-rubbed bronze piano hinge.
OVERHEAD CABINET WITH (1) ADJUSTABLE PLAM SHELF PROVIDE OPENING IN BACK OF CABINET FOR ELECTRICAL OUTLET MICROWAVE OWNER SUPPLY AND INSTALL PROVIDE 1/4" CLEARANCES AT TOP, SIDES AND MIN 1" DEPTH. NO MICROWAVE @ SIM LOCATIONS PLAM PER ELEVATION PLAM UNDERSIDE OF CABINET 1 ' - 3 1 / 4 " E Q E Q 3 / 8 " 1 / 4 " 1 " 3 " 1 / 4 " 4 " V E R I F Y P E R E L E V A T I O N WASTE RECEPTACLE 3/8" THICK DMP-4 BRONZE LEDGE WITH POLISHED FRONT EDGE 5 " 3 1 / 2 " 3 / 1 6 " D M P - 4 D O O R O N O I L - R U B B E D B R O N Z E P I A N O H I N G E R E C E P T A C L E S L O T 1 / 2 " C A B I N E T B O X , P L A M - 3 O N A L L E X P O S E D S U R F A C E S W D B - 1
