A sheet metal scupper is soldered, welded, and secured to the wall and deck or optional wood blocking at the roof edge. The deck membrane extends onto the assembly with a hot air weld applied at least one inch above and all around the hole in the membrane, as well as in front of the hole. A vertical seam metal facade cladding wraps the exterior wall framing. The sloping roof structure supports the deck and waterproofing assembly.
HOT AIR WELD 1" (MIN.) ABOVE AND ALL AROUND HOLE IN MEMBRANE. SHEET METAL SCUPPER SOLDERED/WELDED-SECURED TO WALL AND DECK OR OPTIONAL WOOD BLOCKING HOT AIR WELD 1" (MIN.) IN FRONT OF HOLE IN MEMBRANE. DECK MEMBRANE. PAC-CLAD CITYSCAPE VERTICAL SEAM METAL FACADE SLOPING ROOF STRUCTURE PAC-CLAD CITYSCAPE VERTICAL SEAM METAL FACADE
