A-68XMT — Guardrail & Fin Attachment - 3Rd Floor - B

Architectural · A-68XMT

Guardrail & Fin Attachment - 3Rd Floor - B

Units: imperial
Sheet: A-PK-8.01
Discipline: Architectural

Materials

Metal (misc.)Steel

Elements

Connections / Plates Facades / Cladding Floors / Slabs Railings / Guards

Text on the drawing

3F03-A 2F03-C 9144 [30'] PERFORATED PANEL DIVIDED INTO 3-3048 [10'] X 800 mm PANELS PRE-FABRICATED 76.2mm X 5mm FLAT METAL FRAMING FASTENED TO 2-100mm X 6mm VERTICAL METAL STANCHIONS 2-100mm X 6mm VERTICAL METAL STANCHIONS STRUCTURAL METAL FRAMING 9144 [30'] DIVIDED INTO 3-3048[10'] PANELS
