Architectural · A-67BQE

Reception Counter and Screen Millwork Detail

Materials

Elements

Columns Floors / Slabs Millwork / Casework

About this detail

This millwork detail shows a reception counter assembly featuring a solid surface epoxy terrazzo countertop supported by a three-quarter-inch plywood substrate over hollow structural steel framing of size HSS 3x1 1/2x1/4. The front and side of the counter are finished with high-pressure laminate wood panels and feature a waterfall edge. The assembly incorporates a metal screen extending upward with a metal-clad top cap, and a horizontal power outlet is mounted within the counter framing. Below the main counter, a metal-clad base sits on an epoxy terrazzo floor, supplemented by a floor-mounted tubular foot rail.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
