A specialized window assembly incorporates an internal venetian blind housed within a lead-lined frame. Removable stops are installed on both sides of the assembly for access. The blind tilt control mechanism extends from the bottom of the frame adjacent to a designated throat opening. Dimensions indicate equal spacing and specific profile clearances across the head or jamb section.
1/2" 1/2" 2" 5/8" 2" THROAT OPENING WINDOW - BETWEEN GLASS VENETIAN BLIND (LEAD LINED) W8X REMOVABLE STOP (BOTH SIDES) BLIND TILT CONTROL LEAD LINING AS REQD AS REQD EQ EQ
