An Illusions metal ceiling panel terminates at a perimeter trim with a depth of three and a quarter inches, secured by a perimeter clip fastened to the main tee as required. A main tee is spaced according to the grid plan and suspended with a wire hanger, while a torsion spring and torsion spring hinge connect to the panel. Foam or DC tape is applied as needed between the perimeter trim and vertical surfaces. Field cuts, miters, corner splices, and panel splices are finished to match the panel.
3 1/4" 1/2" 8" MAX. MAIN TEE @ SPACING IND. ON GRID PLAN TORSION SPRING TORSION SPRING HINGE ILLUSIONS PANEL PERIMETER TRIM FIELD CUT & MITER AS REQUIRED (FINISH TO MATCH PANEL) DC TAPE AS REQUIRED PERIMETER CLIP FIELD FASTEN TO TEE AS REQUIRED FIELD FASTEN AS REQUIRED 3/4" 1 1/2" 1 1/4" SPLICE CORNER SPLICE PERIMETER CUT (FINISH TO MATCH PANEL) FULL PANEL ISO N.T.S.
