A pre-fabricated shower surround is trimmed with a one-half inch by two-inch solid surface cap bedded over the shower pan threshold. A cementitious backer board receives the shower surround finish, which is matched to the interior elevation. A continuous waterproof barrier is installed underneath the shower finish. Joint sealant is applied at the junction between the solid surface cap and the adjacent wall board.
SHOWER PAN THRESHOLD BELOW CEMENTITIOUS BACKER BOARD SHOWER SURROUND FINISH - SEE INTERIOR ELEVATION SEALANT 1/2" x 2" SOLID SURFACE CAP TO TRIM PRE-FAB SHOWER SURROUND PROVIDE WATERPROOF BARRIER UNDER SHOWER FINISH
