Concrete stairs connect to a hollow structural section steel tube sized per structural drawings. A one and one-half inch by three-eighths inch wide stainless steel post is welded to a steel plate with its centerline aligned to the precast concrete panel below. The assembly features an offset dimension of twelve inches, a one and one-half inch dimension, and a one-quarter inch dimension.
1 1/2" x 3/8" WIDE STAINLESS STEEL POST WELDED TO STEEL PLATE - CENTERLINE TO ALIGN WITH PRECAST PANEL BELOW HSS STEEL TUBE PER STRUCTURAL 1/8" 12" 1/4" 1 1/2" CONCRETE STAIRS
