This stair railing detail features a stainless steel handrail mounted to glass infill panels set above concrete-filled metal pan treads. The assembly is supported by a steel stringer and a two-inch by two-inch painted steel post. The top of the handrail sits three feet zero inches above the tread nosing, with the glass panel extending to a total height of three feet six inches. A one-inch joint separates adjacent glass panels.
2" X 2" PAINTED STEEL POST STAINLESS STEEL HANDRAIL STEEL STRINGER GLASS PANEL HANDRAIL 3'-6" 3'-0" B4 A521 Sim CONCRETE FILLED METAL PAN TREADS A520 C5 1" 3
