A recessed FSR PWB-320 flat panel display backbox is installed within a framed wall opening measuring one foot two inches square. The assembly receives multiple service lines from above and below, including audio-visual conduits, a building network conduit, and an AC power conduit. A Chief RXF fixed wall display mount, provided by the audio-visual contractor, spans across the backbox unit and is anchored to the surrounding wall construction.
BUILDING NETWORK CONDUIT AV CONDUIT AC POWER CONDUIT FSR PWB-320 OPENING 1'-2" OPENING 1'-2" ℄ CHIEF RXF FIXED WALL DISPLAY MOUNT (PROVIDED BY AVC) AV CONDUIT
