A W8x steel post bears on a one-foot-four-inch by eight-inch by one-half-inch thick end plate welded with five-sixteenth-inch fillet welds. Two seven-eighth-inch diameter through bolts secure the assembly, with threads spoiled after installation. Four-by-four-by-half-inch angles, nine inches long, tie into the post with typical five-sixteenth-inch fillet welds.
TYP 1/2" TYP 2" L4x4x1/2x9" LONG 1'-4"x8"x1/2" THICK END PLATE TYP 5/16 5/16 W8x POST PER PLAN 2-7/8" DIA THROUGH BOLTS SPOIL THREAD AFTER INSTALLATION, TYP TYP 5/16 5/16 TYP
