The rated shaft wall assembly attaches to the underside of the structural steel beam using a slotted track secured with Type S fasteners and stand-off washers spaced at sixteen inches on center maximum, or alternatively with powder-driven fasteners at two feet on center. S12 fasteners spaced at eight inches on center connect the framing members. The assembly includes gypsum board layers and cavity insulation as scheduled.
SLOTTED TRACK TYPE 'S' FASTENER WITH STAND-OFF WASHER AT 16" O.C. MAX OR POWDER DRIVEN FASTENER AT 2'-0" O.C. S12 FASTENERS AT 8" O.C. ATTACHMENT UNDER BEAM SHAFT WALL AS SCHEDULED 1" MIN. 1" MIN.
