An end splash of one-half-inch material stands adjacent to a side partition or full-height cabinet above the countertop. A one-and-one-half-inch typical dimension locates the junction, marking a tangent point at the intersection of the counter assembly and the vertical casework.
END SPLASH COUNTERTOP UNDER COUNTER CABINET WHERE OCCURS SIDE PTN. OR FULL HT. CABINET 1 1/2" TYP. 1/2" MATERIAL AT BACK AND END SPLASHES, TYP. TANGENT POINT
