An 81.87 degree corner louver assembly integrates with an exterior aluminum fin and center line of mullion dimension point. The edge of slab is exposed in the mechanical room with a 4 1/4 inch offset to the louver frame and a 7 1/4 inch dimension to face of glazing or finish. A 3 1/4 inch dimension locates the internal framing component relative to the louver corner geometry. Louver FP-2 aligns with the exterior profile.
8 1 . 8 7 ° 3 1 / 4 " EDGE OF SLAB EXPOSED IN MECHANICAL RM LOUVER FP-2 OF MULLION ALUMINUM FIN F O G 7 1 / 4 " 4 1 / 4 " DIM PT
