Stair stringer connection at the bottom of a run at an intermediate landing. A continuous L5x3x1/4 angle spans between stringers and is fastened with two 5/8-inch diameter by 1 1/2-inch long A325 tension-control bolts, placed within four inches of each stringer. The continuous angle connects to the landing channel with a 3/16-inch fillet weld with a 2 1/2-inch spacing. The stair tread nosing and landing edge align as indicated.
LEADING EDGE OF NOSING TREAD EDGE OF LANDING STRINGER 5" L5x3x1/4 CONT BTWN STRINGERS W/ (2) 5/8" X 1 1/2" A325 T.C. BOLTS, EACH BOLT W/I 4" OF EACH STRINGER LANDING CHANNEL 3/16 2 1/2 ANGLE TO STRINGER A6.2.1 2 A6.2.1 12 TYP ALIGN
