A roof drain is installed through the roof deck over roof sheathing per the manufacturer's instructions. A reinforced membrane waterproofing layer extends beneath the drain flange and is sealed with sealant. Tapered rigid insulation creates a sump around the drain at a slope of less than three inches to one horizontal foot. Structural framing and drain connections are coordinated per structural drawings.
ROOF SHEATHING, SEE STRUCTURAL FOR DRAINS WITH TAPERED RIGID INSULATION OR EQUAL AT DRAIN SUMP LESS THAN 3 INCHES TO 1 HORIZONTAL FOOT ROOF DRAIN, INSTALL PER MANUFACTURER SEALANT REINFORCED MEMBRANE RIGID INSULATION
