Dimensional wall signage featuring material designations M1, P6, and P5 with an overall vertical dimension of four feet and a nine-inch width. The fabricator is required to submit a full-scale signage section in its entirety as specified to the architect, engineer, and designer. The side profile section details the mounting clearances with fractional dimensions of one-quarter inch and one-half inch from the backing wall surface.
M1 2 P6 3 P5 3 FABRICATOR TO SUBMIT A FULL SCALE SIGNAGE SECTION IN ENTIRETY AS SPECIFIED TO A&E + SMA DESIGN. 4' 1/2" 1/4" 9"
