A 1.5-inch diameter painted steel pipe handrail and handrail posts anchor into a structural concrete slab set below concrete pedestal pavers. The assembly aligns with a stainless steel guardrail located beyond the main post. Vertical clearance to the top of the handrail measures 36 inches typical from the finished paver surface.
1 1/2" DIA. PAINTED STEEL PIPE HANDRAIL & HANDRAIL POSTS A728 2 A728 2 TYP. 36" CONCRETE PEDESTAL PAVERS PER FINISH SCHEDULE GUARDRAIL BEYOND ALIGN W/ STAINLESS STEEL STRUCTURAL CONCRETE SLAB STAINLESS STEEL GUARDRAIL BEYOND
