Control schematic for hydraulic gate SE020FP901, incorporating panel 03-FP-532-01 connected via line SE020NSWP903-1. The control console features hand switches HS 03-532-011 and HS 03-532-021 for local/remote operation, alongside momentary open/close hand switches HS 03-532-012 and HS 03-532-022. Position indicators ZI 03-532-013 and ZI 03-532-023 provide 0-100% range feedback. Open and close limit or relay contacts YIO and YIC manage valve positions. The entire control assembly operates on a 120V power supply.
DP934B2 SE020FP901 HS 03-532-011 LSR YIO OPEN YIC CLOSE HS 03-532-012 OC (MOM) HS 03-532-021 LSR YIO OPEN YIC CLOSE HS 03-532-022 OC (MOM) HYG HYD GATE SE020NSWP903-1 SE020FP901 ZI 03-532-013 0-100% ZI 03-532-023 0-100% 120V )3
