Architectural · A-5KTGB

Interior Ceiling Slats and Trim Sections E, F, and G

About this detail

Linear ceiling slat profiles designated as Sections E, F, and G show distinct dimensional layouts with varying widths and reveals. Section E details three parallel slats measuring 5-3/4 inches each with 1/8-inch reveals and a 3/4-inch total depth. Section F incorporates three 5-3/4-inch slats and an additional 4-3/16-inch element with 1/2-inch and 1/8-inch reveals over a 1-1/2-inch depth. Section G provides a single slat profile spanning 5-1/4 inches. Overall runs vary across lengths of 6 feet, 8 feet, and 10 feet per reflected ceiling plans with repeating modules.
