Fabricated metal plate featuring precise geometric dimensions, angled edges, and drilled holes. Two 0.406-inch diameter holes are located in two places, with overall height dimensions of 7.375 inches and 7.70 inches. Angular measurements of 103 degrees reference and 89.55 degrees define the component geometry alongside variable dimension placeholders.
89.55° 7.70 0.13 DIM"G" DIM"F" DIM"D" 2.50 DIM"E" 103° REF 7.375 5.863±0.01 0.39 ∅0.406 (2 PL) DIM"C" DIM"A" 0.13 DIM"B" \ ■o I A £ ) V
